• Intuitive touch operation
  • Brilliant TFT touchscreen (640 × 480, 65536 colors)
  • 1 GByte internal data memory
  • Up to 6 internal analogue inputs
  • Up to two analog outputs
  • 24 external analog and digital channels via all interfaces (Modbus master/slave)
  • Horizontal and vertical line graph
  • Up to six customer-specific process screens
  • Ethernet interface (standard)
  • Integrated web server for online-visualization like at the device
  • Batch report recording
  • Batch control (start, stop, and texts) even via barcode scanner and interface
  • Modbus master function (even with Modbus/TCP)
Product Category: Recorders and Data Acquisition
Recorder Type: Paperless
Dimensions and size: 144mm x 144mm x 119mm (HxWxD)
Inputs / Outputs Option 1 & 2: 3 analog inputs, 6 digital inputs and 1 analog output each
Inputs / Outputs Option 3: 12 digital inputs / outputs
Number of Relay Outputs: 1 (changeover contact)
Internal channels: 6 math channels (optional)
6 logic channels (optional)
6 counters/integrators
1 high-speed counter
Power Supply: 110 – 240V AC
20 – 30V AC/DC
Communications: RS232/485 Modbus (option), Ethernet (option)
HMI: Display – 14,5 cm (5,7”) TFT color screen, 640 x 480 pixel, 65536 colors
Operation –  Touchscreen (resistive)
Certifications: c UL us
Software Tools: Setup program
PCC, PCA3000
PCS, PCAT
